Three-piece necked-in aerosol can

We manufature three-piece necked-in aerosol cans, made of tinplate. The technical dimensions are in conformity with the FEA 214 Standard. According to the customer's requirements the internal surface and the components can be lacquered inside-outside, while the lithogpraphy on the body can be printed in photo quality. Since the cans are containers under pressure, the hermetic  seaming is essential. In order to ensure higher safety, beside the manual water bath, we installed and operate high pressure leak testing units from Bonfiglioli at the end of each lines. The aerosol cans are made with 12 and 15 bar deformation pressure and for request we are able to produce with 18 bar, too.
We are having 4 production lines at the moment on which we are able to provide the cans in  49 mm, 52 mm, 57 mm and 65 mm diameters. Aerosol cans are widely used for packing cosmetics, household chemicals, whipped cream, automotive products, paints and other technical aerosols.










Sizes

Diameter (mm) Height (mm) Brimful capacity (ml) Net volume with liquid propellent (ml)
49 119 210 150
  151 270 200
  185 335 250
  222 405 300
52 105 210 150
  121 230 170
  132 270 200
  161 335 250
  195 405 300
  234 500 382
  244 520 400
57 165 405 300
  207 520 400
  234 590 450
  257 650 500
65 122 405 300
  157 520 400
  195 650 500
  240 800 600
  300 1000 750







For more information about aerosol cans, please contact our sales team.
