Three-piece necked-in aerosol can

We manufature three-piece necked-in aerosol cans, made of tinplate. The technical dimensions are in conformity with the FEA 214 Standard. According to the customer's requirements the internal surface and the components can be lacquered inside-outside, while the lithogpraphy on the body can be printed in photo quality. Since the cans are containers under pressure, the hermetic seaming is essential. In order to ensure higher safety, beside the manual water bath, we installed and operate high pressure leak testing units from Bonfiglioli at the end of each lines. The aerosol cans are made with 12 and 15 bar deformation pressure and for request we are able to produce with 18 bar, too.
We are having 4 production lines at the moment on which we are able to provide the cans in 49 mm, 52 mm, 57 mm and 65 mm diameters. Aerosol cans are widely used for packing cosmetics, household chemicals, whipped cream, automotive products, paints and other technical aerosols.

Sizes

Diameter (mm)	Height (mm)	Brimful capacity (ml)	Net volume with liquid propellent (ml)
49	151	270	200
	185	335	250
	222	405	300
52	132	270	200
	161	335	250
	195	405	300
57	164	405	300
	207	520	400
65	106	335	250
	157	520	400
	195	650	500
	240	800	600
	300	1000	750

For more information about aerosol cans, please contact our sales team.
